Walk-In Fume hood

Large apparatus or complex set-ups may require the use of a Fume Hood specifically designed to meet these requirements. The Walk-In Fume Hood has two vertical rising sashes that allow you to roll in large equipment or portable work stations.

REQUEST A QUOTE

SPECIFICATION

1.Hood body: 1.0mm full-thickness high-quality cold-roll steel sheet is used as a whole; the steel surface is treated, phosphating and other processes, and then electrostatic powder sprayed with epoxy resin, cured at 220°C high temperature. and the surface is smooth, with a thickness of up to 1.15mm~1.2mm.

2.Controller: Intelligent switch with digital display, multiple controls such as power on, fan, lighting, socket, sterilization, damper, etc..

3.Glass sash: two vertical rising sashes, use explosion-proof 5mm tempered glass, aluminum alloy sash handle. It is designed by the weight balance method in the mechanical principle, and the left and right are connected by synchronous wheels.

4.Lighting: Equipped with LED 30W purification lamp, the luminosity is greater than 300LUX.

5. Fume hood liner liner and Baffle: Use 5mm Compact grade laminate, baffle fixed with PP material.

6. Junction box: The junction box with circuit board and AC contactor makes wiring more convenient. Suitable for 110V-230V voltage.


7.Standard accessories:

4x Electrical Outlets

1x 250 or 315mmφ PP hood.


8.Optional accessories:

PP oval cupsink

Remote Controlled Fixture gas&water faucet

Explosion-proof light

Distillation Grid Kit

Ductwork

Exhaust blower



Features

• By-pass airflow design with variable air volume compatibility

• Engineered Three section baffle system for proper air distribution and constant face velocity.

• Double wall construction for installation of plumbing and electrical fixtures and concealed routing of piping and wiring.

• Chemical-resistant fume hood liner and baffle. Baffles are removable for cleaning

• Removable service access of side panels for access to plumbing and electrical wiring.

• The junction box on top of fume hood with circuit board and AC contactor makes wiring more convenient. Suitable for 110V- 230V voltage.


Model

WFH-120

WFH-150

WFH-180

External Dimension

(W*D*H)(mm)

1200*850*2350

1500*850*2350

1800*850*2350

Internal Dimension

(W*D*H)(mm)

960*680*2000

1260*680*2000

1560*680*2000

Exhaust air volume

700-1300m³/h

900-1700m³/h

1300-2100m³/h

Air Velocity

0.3~0.7 m/s
