PP Fume Hood
MAX LAB PP Fume Hoods are engineered for superior chemical resistance and durability, making them an essential addition to chemical, biological, and pharmaceutical laboratories. Constructed from high-quality polypropylene (PP), these fume hoods excel in environments requiring resistance to strong acids, alkalis, and corrosive substances, and perfect for labs that demand corrosion-resistant and lightweight equipment. Explore our range today and discover the ideal PP Fume Hood for your laboratory’s ventilation needs.
PP(Polypropylene) Fume Hoods are made of high-quality non-corrosive polypropylene with excellent chemical resistance. PP increases the product’s tensile strength and improves its thermal characteristics.PP Fume Hoods protect laboratory staff from noxious fumes released by acids, dangerous gas and organic solutions – materials and acids which regular steel hoods may not withstand.
Product Details
PP Fume Hood
MATERIAL INTRODUCTION
PP is polypropylene. English name: Polypropylene, referred to as: PP, commonly known as: pp
Polypropylene is the representative of polyalpha-olefins, a thermoplastic resin made from propylene polymerization, whose monomer is propylene CH2 = CH3. It is one of the lighter ones in the common plastic, and its electric performance is excellent, but it can be used as an application of high humidity and high frequency insulation materials. It has good acid resistance, easy cleaning, oxidation resistance and good surface gloss.
Specification
1.Hood body&base cabinet: 8-12mm porcelain white PP (polypropylene) sheets, welded into one piece, welded by the same color and homogeneous electrode.
2.Standard Work surface: 12mm porcelain white PP (polypropylene) sheet (Edge banding and Thicken to 24mm)
Optional: Phenolic Resin/Epoxy Resin/Stainless Steel/Ceramic/Trespa/Granite/Marble.
3.Controller: Intelligent switch with digital display, multiple controls such as power on, fan, lighting, socket, sterilization, damper, etc.
4.Glass sash: Use explosion-proof 5mm tempered glass, PP material sash handle. It is designed by the weight balance method in the mechanical principle, and the left and right are connected by synchronous wheels.
5.Lighting: Equipped with LED 30W purification lamp, the luminosity is greater than 300LUX,
6.Fume hood liner and Baffle: Use 8mm porcelain white PP (polypropylene) plate.
7. Junction box: The junction box with circuit board and AC contactor makes wiring more convenient. Suitable for 110V-230V voltage.
8. Standard accessories:
1x bench-mounted single water tap
1x PP oval cupsink
4x Electrical Outlets
1x 250 or 315mmφ PP hood.
9.Optional accessories:
Remote Controlled Fixture gas&water faucet
Explosion-proof light
Distillation Grid Kit
Acid and flammable base cabinet
Exhaust Fan and Ductwork
Standard Dimensions
|
External Dimension (W*D*H)(mm) |
1200*850*2350 |
1500*850*2350 |
1800*850*2350 |
|
Internal Dimension (W*D*H)(mm) |
1000*680*700 |
1300*680*700 |
1600*680*700 |
|
Base Cabinet Dimension (W*D*H)(mm) |
1200*800*850 (Can remove) |
1500*800*850 (Can remove) |
1800*800*850 (Can remove) |
|
Exhaust air volume |
700-1300m³/h |
900-1700m³/h |
1300-2100m³/h |
|
Air Velocity |
0.3～0.8 m/s |
||
Hood body&Base cabinet:
8-12mm porcelain white PP (polypropylene) sheets, welded into one piece, welded by the same color and homogeneous electrode.
Standard Work Surface:
12mm porcelain white PP (polypropylene) sheet (Edge banding and Thicken to 24mm)
Optional: Phenolic Resin/Epoxy Resin/Stainless Steel/Ceramic/Trespa/Granite/Marble.
Inner:
Use 8mm porcelain white PP (polypropylene) plate.
Baffle:
Use 8mm porcelain white PP (polypropylene) plate.
Controller:
Intelligent switch with digital display, multiple controls such as power on, fan, lighting, socket, sterilization, damper, etc..
Glass sash:
Use explosion-proof 5mm tempered glass, PP material sash handle. It is designed by the weight balance method in the mechanical principle, and the left and right are connected by synchronous wheels.
Lighting:
Equipped with LED 30W purification lamp, the luminosity is greater than 300LUX.
Air foil:
Aerodynamic curve allows air to sweep the work surface maximizing containment. Reduces energy consumption by 7-10% compared to flat air foils.
By-pass Slots:
By-pass airflow design with variable air volume compatibility. Compensating opening that maintains a relatively constant volume exhaust through a Fume Hood regardless of sash position and that functions to limit the maximum face velocity as the sash is lowered.
Junction box:
The junction box with circuit board and AC contactor makes wiring more convenient. Suitable for 110V-230V voltage.
Service access:
Removable service access on both sides for easy installation and maintenance of circuits, gas circuits and other accessories.
Sewerage system: Using high-density PP material anti-siphon bottle trap, corrosion resistance, acid and alkali resistance and inorganic substances, with filtering and odor blocking functions.
Features
• By-pass airflow design with variable air volume compatibility
• Hood entrance is framed with inward-angled members to minimize turbulence and provide smooth air movement in hood at face velocities
• Engineered Three section baffle system for proper air distribution and constant face velocity
• Double wall construction for installation of plumbing and electrical fixtures and concealed routing of piping and wiring
• Chemical-resistant fume hood liner and baffle. Baffles are removable for cleaning
• Removable service access of side panels for access to plumbing and electrical wiring
• The junction box on top of fume hood with circuit board and AC contactor makes wiring more convenient. Suitable for 110V- 230V voltage
