Drench Shower EW-17

Ceiling Mounted Emergency Drench Shower (Pull Handle Activation)

Ideal for laboratories, schools and general light duty indoor use, this ceiling mounted eye/face wash unit executive standard is ANSIZ358.1-2014 (American Standard), water flows out from the top of shower rose and is used by pulling the shower rod.

Material: SS304

Pipework: The main pipe is made of stainless steel, with good corrosion resistance

Surface treatment: fine polishing to increase the corrosion resistance of the product

Valve: Two piece stay open valve

Shower Rose: Spinning type crimping process design, diameter 250mm

Test pressure: 1.5Mpa

Ambient temperature: 0°C～40°C

Spray water flow: ≥76 L/min

Switch: The sign indicating the operation diagram and text description is placed near the hand-pull switch

Executive standard: ANSIZ358.1-2014 (American Standard)

Increase the utilization rate of narrow working space and laboratory space, the wall-mounted eyewash does not occupy floor space, and is simple and convenient to use

Note: After the eye wash stops using, the water in the pipe will be automatically drained

Executive standard: ANSIZ358.1-2014 (American Standard)

Key Features:

Quick Activation: Pull-lever or push-plate design for instant use.

Durable Materials: Made from corrosion-resistant stainless steel or polyethylene.

Compliance: Meets ANSI Z358.1 and OSHA safety standards.

Easy Maintenance: Self-draining systems and tamper-proof designs.

Versatile Installation: Wall-mounted, floor-standing, or portable options.

Applications:

Chemical and research laboratories

Industrial and manufacturing facilities

Educational and school labs

Pharmaceutical and biotechnology plants
